Pulse Bag-type Collector

•
•

Inquiry Form

Applications of Pulse Bag-type Collector LHZ:
Our pulse bag-type collectors has a simple structure, convenient installation and maintenance, long service life and high dust collection efficiency; as a result, our industrial dust collectors are widely used for dust pollution control applications in cement and asphalt processing, wood, food, textile, paper, plastic, paint and minerals processing industries.

Features of Pulse Bag-type Collector LHZ:
1. Dust collection types: pulsed dust-collection; separator dust-collection.
2. Rational air distribution enables dust agglomeration during filtering process, which help reduce the load of filter bag and the frequency of pulse.
3. Simple and convenient installation and removal for filter bags. And resistance welded frame is so smooth that avoided abrasion of filter bags.
4. We can choose different filter bags for different requirements.

Parameters of Pulse Bag-type Collector LHZ:

Data Spec	Filter area (m2)	Velocity of wind m/min	Thickness of inlet (g/m3 )	Thickness of output (mg/m3)	Running resistance (MPa)	Pressure of deashing (MPa)	Air consumption m3/min	Outside measurement L×W×H
LHZ-40	40	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.3	1995×2800×4600
LHZ-60	60	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.3	2295×3142×4600
LHZ-92	92	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.3	3015×3332×4600
LHZ-120	120	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.5	3735×3332×4600
LHZ-150	150	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.5	4645×3332×4600
LHZ-225	225	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	0.6	5418×3334×4948
LHZ-285	285	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	1.2	5718×3040×6140
LHZ-410	410	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	1.2	5718×3400×6970
LHZ-635	635	0.5~2	60~300	≤50	0.78~1.5	0.6~0.7	1.5	5974×3900×8260
